Gigabyte B550 X GAMING AMD Socket AM4 DDR4 PCIe 4.0 Motherboard
Brand: Gigabyte Quick Find: 77195 17 in stock£96.10
Overview
This AMD B550 chipset motherboard supports Socket AM4 processors and dual-channel DDR4 memory up to 128GB. It features PCIe 4.0 connectivity for high-speed storage and graphics, alongside Realtek 2.5GbE LAN for fast networking. Connectivity options include USB-C, HDMI and DisplayPort outputs for compatible systems.
Read More
Specifications
| Specification | Value |
|---|---|
| Package Type | Retail |
| Warranty | 3 Years |
| BIOS | 1 x 128 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Chipset | AMD B550 |
| CPU Interface | Socket AM4 |
| CPU Support | https://www.gigabyte.com/uk/Motherboard/B550-X-GAMING-rev-1x/support#Support-Cpu-Support |
| RAM Technology | DDR4 (Dual Channel) |
| RAM Slots | 4 x 288-pin |
| RAM Speeds | Up to DDR4 3200 |
| Max. Memory Support | 128GB |
| PCI Express 3.0 x16 | 1 |
| PCI Express 4.0 x16 | 1 |
| PCI Express 3.0 x1 | 2 |
| S-ATA 6Gb/s Port(s) | 4 |
| RAID | Raid 0/1/10 |
| M.2 Socket(s) | 1 x PCIe Gen 4.0 x4/SATA, 1 x PCIe Gen 3.0 x4/SATA |
| LAN Speed | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| On-Board Audio | Realtek Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel |
| On-Board Video | Processor with integrated graphics is required |
| Back USB 2.0 Port(s) | 2 |
| Back USB 3.2 Port(s) Type-A Gen 1 | 3 |
| Back USB 3.2 Port(s) Type-A Gen 2 | 1 |
| Back USB4 Port(s) Type-C | 1 |
| Back HDMI Port(s) | 1 |
| Back DisplayPort(s) | 1 |
| Back LAN Port(s) | 1 |
| Back Audio Jack(s) | 2 |
| Back S/PDIF Output Port(s) | 1 |
| Back Other Port(s) | 2 x antenna connectors (2T2R) |
| Back Button(s) | 1 x Q-Flash Plus |
| 24-pin ATX Power | 1 |
| 8-pin ATX Power | 1 |
| USB 2.0 Header(s) | 2 |
| USB 3.2 Header(s) Gen 1 | 2 |
| Front Panel Audio Connector | 1 |
| Internal Other Port(s) | 3 x addressable RGB Gen2 LED strip headers, 1 x RGB LED strip header |
| Form Factor | Standard ATX |
| Product Width | 244mm |
| Product Length | 305mm |
| Package Width | 29.40cm |
| Package Length | 34.50cm |
| Package Height | 8.00cm |
| Net Weight | 1.96Kg |
| Gross Weight | 2.37Kg |
| Special Features | AMD Socket AM4: Supports AMD Ryzen 5000 / 4000 / 3000 Series Processors., Hybrid Digital twin 8+2 phases VRM solution., Dual Channel DDR4: 4xDIMMs with EXPO Memory Module Support., PCIe EZ-Latch: PCIe slot with Quick Release and Screwless Design., M.2 EZ-Latch Plus/ Click: M.2 slots and heatsinks with screwless design., Ultra-Fast Storage: 2 x M.2 slots, including PCIe 4.0 x4., Efficient Thermal: VRM Thermal Armor Advanced and M.2 Thermal Guard., Fast Networking: 2.5GbE LAN., Extended Connectivi |
What's in the box
- Motherboard
- Manual
- Quick Installation Guide
- 2 x SATA cables
- M.2 screw 5 One pack of M.2 thick/thin rubber pads
